» Fully Automatic Vertical Autoclaves are specially designed for medical, clinical, bacteriological & research laboratories, pharmaceuticals, fertilizer plant, breweries, soft drink mfg. etc.
» Double walled construction with Inner chamber (boiler) made of Stainless Steel 16 SWG sheet - grade and Outer shell of Stainless Steel sheet - 304 grade Mirror polish.
» The Boiler and outer shellis provided with air insulation.
» Lid is made of die pressed Thick Stainless Steel plate & is equipped with Pressure gauge, Steam release/Exhaust valve & Spring loaded safety valves.
» Foot lifting arrangement for lid.
» Fully Argon welded to avoid steam and pressure leakage.
» Heavy duty industrial flange heaters.
» Full sterilization cycle including Air purging, Sterilizing hold time, Cycle end with release/exhaust of pressure & alarm is automatic.
» Microprocessor based Controller with time and temperature programmable by user.
» Temperature Sensor : PT-100
» Perforated basket made of Stainless Steel sheet - 304 grade.
» Operates on 230Volts AC Single phase 50 Hz.

Temperature Range 121 °C to 125 °C
Temperature Resolution 0.1 °C
Pressure Range 15 PSI to 20 PSI
Factory Set at 15 PSI


Safety Features :

A. Low water level alarm with Heater Cut-off.

Model Size in Inches Capacity (LTRS) No.Of Baskets Watts
SEE-1AA 10 Dia x 18 Depth 22 1 2000
SEE-2AA 12 Dia x 20 Depth 35 1 2000
SEE-3AA 14 Dia x 22 Depth 52 1 3000
SEE-4AA 16 Dia x 24 Depth 90 1 4000
SEE-5AA 18 Dia x 24 Depth 95 1 4000
SEE-6AA 18 Dia x 30 Depth 120 2 4500
SEE-7AA 22 Dia x 30 Depth 175 2 5000
